2200lbs Electric Chain Hoist, 13 ft Lifting Height, Single Phase Overhead Crane with Double Chains, 1 Ton Portable Winch, Electric Hoist Winch with Wired Remote Controller for Garage & Workshop

SpecificationsColor: Orange ColorHousing Material: Aluminum AlloyChain Material: 20Mn2Hook Material: Manganese SteelRated Voltage: 110VRated Power: 1300WStyle: ModernType: Double ChainsMotor Protection Grade: IP55Insulation Class: FChain Diameter: 6.3mm/0.25inchMotor Type: Pure Copper MotorPlug Type: American Standard Maximum Load Capacity: 1T/2200lbsLifting Speed: 3.05m/min (10ft/min) Lifting Height: 3.05m/10ftHandle Switch Wire Length: 2.8m/9.19ftGross Weight: 28kg/61lbsPackage Size: 51*28.5*39cm/20.9*11.22*15.35inchMachine Body Size (L*H): 45*15cm/17.72*5.91inchPackage Included1* Electric Chain Hoist1* Lifting Strap1* Chain Bag1* English Manual1* English Inspection Certificate1* Chinese&English WarningNotes1.If the specified object is too large or the object cannot be hung directly on the hook, you will need to tie a longer webbing around the object and then hook the webbing with the hook to lift the object.2.Please ensure that all persons in the immediate area are informed and warned of the need for safety before lifting and moving heavy objects. If necessary, set up a lifting area to remind unoccupied and uninvolved persons that they are not allowed in.3.Please do not leave lifted heavy objects unsupervised for long periods as this may cause injury.4.The lifting weight shall not exceed the maximum load capacity of the product (Single chain weighing up to 1100 lbs, double chain weighing up to 2200 lbs). Please do not use multiple chain hoists to lift a heavy object or pull a heavy object horizontally.5.Please do not use the chain when it is bent or twisted. Please do not jerk the chain when it is not moving and stop immediately, then start debugging the product.6.Please do not throw the product to avoid damage.7.For the uniformly distributed work cycle, the maximum operation time of the hoist per hour is 25%, and it can handle up to 150 starts per hour. When used for infrequent working hours, it can run for 30 minutes from the cold start, with a maximum of 200 starts per hour.8.Before using the machine, please read carefully all the safety instructions in the product manual.9.Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before you order."

• 2200lbs Electric Chain Hoist: The aluminum alloy housing, 20Mn2 chain, and manganese steel hook with high strength and good rigidity can resist wear, corrosion, shock, and deformation. Also, the silver point switch, high-speed synchronous gear, and three-wire power cord can be used for a long time and the high protection grade (IP55) allows it to be used in different environments.
• Productivity Boosting: 1300W pure copper motor lifts heavy loads to 10ft in 60 seconds to boost productivity and slash labor costs!
• Stable Performance: The high-speed bearing can ensure that the bearing rotation gap of the motor remains unchanged under long-term use. It has a stable rotor axially with high motor force, which ensures good working performance. Meanwhile, the pure copper motor with good heat dissipation and good stability can provide strong power for lifting with low noise, giving you a more comfortable working environment.
• Thoughtful Design: When the anti-rush top limiter touches the hook, the machine can automatically stop lifting to avoid damaging the machine due to excessive lifting. Meanwhile, the hook with a safety latch can rotate 360° to lift objects in all directions and allows the machine to be fixed stably at a high place or connected to most trolleys or beam clamps while promoting safety.
• Widely Used: It is suitable for factories, docks, warehouses, logistics, construction sites, car manufacturers, railways, construction, garages, ceilings, attics, barns, lofts, etc. for lifting regular or irregularly shaped objects, and can be used for various lifting equipment such as single column, wall column, and crane."
